EXJ1M SYSTEM CONFIGURATION

CONFIGURATION OF SYSTEM
System type Selection [0=T5381,1=T5381A] .............> 1

CONFIGURATION OF TEST HEAD
Number of Test Head [1,2] ...........................> 2

CONFIGURATION OF TEST HEAD 1
Test Head type
1.160CH AG HEAD
2.320CH AG HEAD
3.160CH AE HEAD (PE:BGL-016090)
4.160CH AE HEAD (PE:BGL-016090X02) [1,2,3 OR 4] ....> 1

Pin configuration
DR pin CHILD A1 [ 1-30] ........> 1-30
DR pin CHILD A2 [ 1-30] ........> 1-30
IO pin CHILD A [33-52] ........> 33-52
DR pin CHILD B1 [ 1-30] ........> 1-30
DR pin CHILD B2 [ 1-30] ........> 1-30
IO pin CHILD B [33-52] ........> 33-52

CONFIGURATION OF TEST HEAD 2
Test Head type
1.160CH AG HEAD
2.320CH AG HEAD
3.160CH AE HEAD (PE:BGL-016090)
4.160CH AE HEAD (PE:BGL-016090X02) [1,2,3 OR 4] ....> 1

Pin configuration
DR pin CHILD A1 [ 1-30] ........> 1-30
DR pin CHILD A2 [ 1-30] ........> 1-30
IO pin CHILD A [33-52] ........> 33-52
DR pin CHILD B1 [ 1-30] ........> 1-30
DR pin CHILD B2 [ 1-30] ........> 1-30
IO pin CHILD B [33-52] ........> 33-52

CONFIGURATION OF DPU
TEST HEAD 1 Number of DC [1-4] ..................> 1-4
Number of PPS [1-12] .................> 1-8
0.8A PPS OPTION [Y or N] ...............> No
2A PPS OPTION [Y or N] ...............> Yes

TEST HEAD 2 Number of DC [1-4] ..................> 1-4
Number of PPS [1-12] .................> 1-4
0.8A PPS OPTION [Y or N] ...............> No
2A PPS OPTION [Y or N] ...............> Yes

CONFIGURATION OF TG
Option clock edge 25-32 [Y or N] ....................> Yes
Option clock edge 33-40 [Y or N] ....................> Yes

CONFIGURATION OF ALPG
X.Y-Address [0=12bit,1=16bit] ........................> 1
Sub PG [Y or N] .................................> Yes

CONFIGURATION OF FM
Number of FM board [0-6] ...........................> 4
Size of FM board [1-4] (1=4M,2=16M,3=72M,4=288M) ........> 3
FM X.Y-Address [0=12bit,1=16bit] .....................> 1

CONFIGURATION OF MRA
MRA OPTION EXIST [Y or N].........................> No

CONFIGURATION OF VRAM
VRAM OPTION 2 [Y or N] .............................> Yes
